The world’s first battery-powered, completely wireless, hyper-portable,
mini C-arm providing unparalleled digital fluoroscopic imaging capabilities.
This mini C-arm is designed for use in clinics, operating rooms, in the field
at point of injury/care or wherever extremity imaging is desired.
• Battery-powered, lightweight (16lbs.) carbon fiber, cordless C-arm offering true portability
• Sophisticated software algorithms provide exceptional real-time imaging and anatomical clarity
• Wireless Tablet enables ergonomic placement directly in line of sight for enhanced visualization
• Position the C-arm on its front or side to quickly acquire images, including weight bearing
• Compact hindrance free design allows for use directly on the surgical table/arm board
• Custom sterile drapes allow both C-arm and Tablet to be used in the surgical field
• Modular system offers flexibility to purchase the accessories you need, not those you don’t
Image Receptor – CsI scintillator on Complementary Metal Oxide Semiconductor (CMOS)
Image Receptor Pixel Array – 1.5.k x 11.5k
Image Receptor Pixel Size – ~99 µm
Field of View – Primary collimation: 15 x 15 cm (6 x 6 in), Secondary collimation: 10 cm (4 in) dia
Tube Voltage Range – 40 to 80 kV
Tube Current Range – 65 to 370 µA
Pulse Rate – 10 pulses per second
Focal Spot – 0.04 mm nominal
Tablet Screen – 34 cm (13.3 in) diagonal 1920 x 1080 resolution Touchscreen
Live Image – 15 cm x 15 cm (6 in x 6 in)
Water Ingress – C-arm: IPX3 (spraying water) Footswitch: IPX8 (immersion)
Source to Detector Distance (SDD) – 45 cm (17.7 in)
Minimum Source to Skin Distance (SSD) – 10 cm (4.0 in)
C-Arm Free Space (Functional SSD) – 34 cm (13.4 in
C-Arm Depth of Arc – 31 cm (12.2 in)
Networking – DICOM 3.0 compliant
Wireless Security – WPA2 encryption
C-arm and Battery Weight – 7.2 kg (16.0 lb)
Tablet Weight – 1.5 kg (3.3 lb)
Footswitch Weight – 0.7 kg (1.5 lb
The Turner Smart-C comes complete with 12 months of coverage.
We also offer full-service agreements for 3 and 5 years, which can be included with your financing bundle.
The service agreement includes a free loaner program where a replacement Smart-C will arrive in less than 48 hours!
